LITHIUM-ION BATTERY FIRE EXTINGUISHERS
FIRE PROTECTION TO PREVENT PROPAGATION OF HEAT
AVD – EXTINGUISHER – Synergy Fire Systems Compared to older lead type batteries, lithium-ion batteries are popular because of how much power they can provide at a given size and weight. Lithium-ion batteries are naturally flammable and particularly sensitive to high temperatures. Heat causes these battery packs to deteriorate far more quickly than they otherwise would. A lithium-ion battery pack that malfunctions can catch fire and inflict extensive harm.
Aqueous Dispersion of Vermiculite Fire Extinguisher AVD
An aqueous dispersion of chemically exfoliated vermiculite is the AVD Fire Extinguisher agent. It is used as a mist on lithium battery fires to put them out and stop them from spreading.
When used as a mist, the Synergy Fire Systems Lithium-ion Battery fire extinguisher with AVD agent effectively blocks the spread of heat related to lithium batteries. In addition, the AVD coating serves as a fire buffer. A film is formed over the top of the fire by the mist's vermiculite particles adhering to the fuel's surface.
The film dries instantly, creating a non-flammable oxygen barrier between the fuel and the atmosphere as a result of the high aspect ratio platelet particles overlapping and binding together. The fuel source is cooled by this process, and as the water in the AVD evaporates, vermiculite platelets start to accumulate and the fire is contained.
IDEAL USE
TECHNICAL SPECIFICATIONS
| MODEL | KFLIHQ-1 | MODEL | KFLIHQ-1 |
| Capacity | 1 Ltr | Design | Nozzle |
| Fire Rating | 3A | Height (Approx.) | 325 mm |
| Diameter (Approx.) | 86 ± 5 mm | Average Discharge time | 25 Sec |
| Average Range of throw | 1.5 – 2 m | Average % Discharge | 97% |
| Operating Temperature | +5 °C to +60 °C | Service/Max. service/Test Pressure | 15 / 18 / 35 bar |
| Expelling Agent | Nitrogen (UHP Grade) | Empty Weight (Approx.) | 2.2 kg |
| Full Weight (Approx.) | 4.2 kg | Shipping Weight (Approx.) | 4.5 kg |
| Mounting Bracket | VEHICLE MOUNTED / WALL MOUNTED |
| MODEL | KFLIHQ-2 | MODEL | KFLIHQ-2 |
| Capacity | 2 Ltr | Design | Nozzle |
| Fire Rating | 5A | Height (Approx.) | 370 mm |
| Diameter (Approx.) | 106 ± 5 mm | Average Discharge time | 50 Sec |
| Average Range of throw | 1.5 – 2 m | Average % Discharge | 97% |
| Operating Temperature | +5 °C to +60 °C | Service/Max. service/Test Pressure | 15 / 18 / 35 bar |
| Expelling Agent | Nitrogen (UHP Grade) | Empty Weight (Approx.) | 2.7 kg |
| Full Weight (Approx.) | 5.7 kg | Shipping Weight (Approx.) | 6.1 kg |
| Mounting Bracket | VEHICLE MOUNTED / WALL MOUNTED |
| MODEL | KFLIHQ-6 | MODEL | KFLIHQ-6 |
| Capacity | 6 Ltr | Design | Hose with Nozzle |
| Fire Rating | 13A | Height (Approx.) | 570 mm |
| Diameter (Approx.) | 150 ± 5 mm | Average Discharge time | 120 Sec |
| Average Range of throw | 1.5 – 2 m | Average % Discharge | 97% |
| Operating Temperature | +5 °C to +60 °C | Service/Max. service/Test Pressure | 15 / 18 / 35 bar |
| Expelling Agent | Nitrogen (UHP Grade) | Empty Weight (Approx.) | 4.9 kg |
| Full Weight (Approx.) | 10.9 kg | Shipping Weight (Approx.) | 11.3 kg |
| Mounting Bracket | WALL MOUNTED |
| MODEL | KFLIHQ-9 | MODEL | KFLIHQ-9 |
| Capacity | 9 Ltr | Design | Hose with Nozzle |
| Fire Rating | 13A | Height (Approx.) | 640 mm |
| Diameter (Approx.) | 180 ± 5 mm | Average Discharge time | 170 Sec |
| Average Range of throw | 1.5 – 2 m | Average % Discharge | 97% |
| Operating Temperature | +5 °C to +60 °C | Service/Max. service/Test Pressure | 15 / 18 / 35 bar |
| Expelling Agent | Nitrogen (UHP Grade) | Empty Weight (Approx.) | 5.5 kg |
| Full Weight (Approx.) | 14.5 kg | Shipping Weight (Approx.) | 15.0 kg |
| Mounting Bracket | WALL MOUNTED |
